2011 Eurocraft EXPLORER 4444m

MAIN CHARACTERISTICS

Builder: Eurocraft Cantieri Navali S.r.l. (Italy)

Model: Eurocraft Explorer 44

Naval Architect: Eurocraft Cantieri Navali

Exterior Designer: Eurocraft Studio

Interior Designer: Owner / Eurocraft Studio

Type: Motor Yacht / Explorer Yacht / Expedition Yacht / Superyacht / Tri-deck Yacht

Hull Type: Displacement

Hull Material: Steel

Superstructure Material: Aluminium

Decks: Teak

Built: 2011

Refit(s): 2016 / 2021 / 2023

LOA: 43.50 m (142’ 9”)

LWL: 38.17 m (125’ 3”)

Beam: 8.20 m (26’ 11”)

Draft (full load): 3.00 m (9’ 10”)

Gross Tonnage: 478 GT

Net Tonnage: 143 T

Displacement: 425,000 kg (936,965 lb)

Location: Italian Riviera, Italy

CONSTRUCTION

Hull Material: Steel

Superstructure Material: Aluminium

Decks Material: Teak

Paint: Awlgrip

Number of Decks: 4

CLASSIFICATION

Flag of Registry: Portugal

Port of Registry: Funchal, Madeira

Classification: IACS Society Bureau Veritas

Additional Class Information: Commercial Vessel - Unrestricted Navigation

Built to Commercial Compliance: RINA Charter Class

MARPOL Code compliant

SURFACES

Total Interior: 281 m2 (3,025 ft2)

Sun Deck: 107 m2 (1,152 ft2)

Bridge Deck: 59 m2 (635 ft2)

Upper Saloon: 27 m2 (291 ft2)

Lobby and Day Toilet: 8 m2 (86 ft2)

Guest Cabins: 24 m2 (258 ft2)

Main Deck: 148 m2 (1,593 ft2)

Main Saloon: 90 m2 (969 ft2)

Lobby and Day Toilet: 10 m2 (108 ft2)

Owner’s Cabin: 48 m2 (517 ft2)

Lower Deck: 67,5 m2 (727 ft2)

VIP Cabin: 35 m2 (377 ft2)

Double Cabin: 16 m2 (172 ft2)

Twin Cabin: 13 m2 (140 ft2)

Lobby: 3,5 m2 (38 ft2)

PROPULSION

Type / Fuel: Twin Screw Diesel

Main Engines: 2 x 805 Hp (600 kW) MTU 12V 2000 M60

Engine Hours: Port 6,542 h; Starboard 6,539 h - After W6 480 h (February 2023)

Maximum Speed: 13.5 knots @ 1700 RPM

Consumption & Range @ Max Speed: 250 l/h – 5,670 NM

Cruising Speed: 10 knots @ 1150 RPM

Consumption & Range @ Cruise Speed: 90 l/h – 11,660 NM

Economical Speed: 6 knots @ 600 RPM

Consumption & Range @ Eco Speed: 25 l/h – 25,000 NM

Drives: Propeller shafts

Shafting: Conventional shaft line

Engine Mounts: VULKAN

Engines Exhaust System: Underwater

Gearboxes: ZF 2550

Propellers: DETRA 5-blades

TANKAGE

Fuel Capacity: 105,000 l (27,738 US Gallons)

Fresh Water Capacity: 23,270 l (6,147 US Gallons)

Water Maker: 160 l (42 US Gallons)

Grey and Black Water Tanks: 4,270 l (1,128 US Gallons)

ACCOMMODATION

Guest Accommodations: 12 Guests in 6 en-suite staterooms

Crew Accommodations: 9 Crew in 5 en-suite cabins

Minimum Safe Manning: 5 Crew

LAYOUT

Lower Deck:

• On the lower deck there are three guest staterooms, a twin, a double and a VIP all built with fine materials. All bathrooms have marble finishings. In the full-beam VIP stateroom, there is a sofa, a vanity and a bathroom with Jacuzzi and separate toilet
• There is also a bunk-bedded crew cabin forward, crew mess and laundry room
• Two other twin crew cabins are located aft

Main Deck:

• Main saloon with bar and formal dining area
• The main saloon connected with the main dining make an ample space with two sofas, a bar, TV and entertainment systems
• Fully equipped professional galley and pantry are also located on this deck
• Day toilet
• Owner’s Stateroom: A studio separates the main lobby from the full-beam Owner’s stateroom. This stateroom features plenty of natural light thanks to four windows. You will also find a sofa and a vanity. The marble finished His and Hers bathroom is equipped with Jacuzzi, shower, and separate toilet

Bridge Deck:

• There are two twin guest staterooms and a lounge with bar, TV and entertainment systems
• Aft of the vessel, there is a dining area
• Day toilet
• Captain’s cabin and twin crew cabin are adjacent to the wheelhouse

Sun Deck:

• The sun deck is a wide space for sunbathing equipped with a Jacuzzi pool, a shower and a bar

ELECTRICAL EQUIPMENT

Electrical System: 400V – 50 Hz

Generators: 3 x ONAN 80 kW 400V AC, 3-phase, 50 Hz

Generator Hours (February 2023):

• Port: 8,066 h - After revision 731 h
• Centre: 8,060 h - After revision 621 h
• Starboard: 7,963 h - After revision 714 h

Generator Fuel Consumption: 10 l/h

Generator Exhaust System: Side Hull

Shore power connection

Shore Power Transformer: Frequency Converter 320/520V AC, 3-phase 40/70 Hz > 400V AC, 3-phase +N, 50 Hz, 100 KVA

Batteries: 24V

Generator Start: Automatic

UPS (Uninterruptible Power Supplies): 0 Passage

AUXILIARY MACHINERY

Steering System: Hand steering normal operation from wheelhouse or wings and hand steering in emergency in the control room, automatic pilot in the wheelhouse

Engine Room Ventilation: 2 x GIANNESCHI EL3630, natural and mechanical exhaust fans

Bow Thruster: NAIAD MARINE VT 75 - 83 kW

Stabilizers: 4 x NAIAD MARINE Mod. 525 hydraulic zero speed stabilizers

Helm/Wing Station Controls

Fuel & Oil System:

• Fuel Filters: Duplex RACOR filters
• Fuel Oil Separator: CJC PTU 1 27/54
• Fuel Transfer Pump: TRILUB 140R46U8 6-V-W115
• Fuel filling pump
• Oily bilge water separator
• Dirty oil pump

Fresh Water System:

• Fresh Water Makers: 1 x SEAFRESH H206A.F 160 l (42 US Gallons)
• Fresh water treatment plant
• Fresh Water Pressure: 2 x CALPEDA B NG 6/22/A, 230/400V, 3-phase, 50 Hz, 1.5 kW
• Hot & Cold Circulation Pump: GIANNESCHI Z40 230/400V, 3-phase, 50 Hz
• Hot Water Boilers: 2 x GIANNESCHI

Black & Grey Water System:

• Black & grey water treatment plant TRITON
• Marine WC's (Toilets/Bidets)
• EVAC sanitary vacuum system
• Grey water discharge pumps

AC & Ventilation System:

• Air conditioning FRIGIT
• 3 x Air compressors MATTEI, ERC 5H 400
• Provision refrigeration

Firefighting & Bilge System with automatic and manual pump

Hydraulic system with hydraulic power packs

NAVIGATION EQUIPMENT

MTU electronic engine controls

MTU electronic engine displays

Navigation bridge computer

5 x Monitors

FURUNO 2117 X-Band radar

FURUNO 2137 S-Band radar

Multifunctional workstation

TRANSAS chart plotter

UPS

C. PLATH Jupiter magnetic compass

Wheel Mark SIMRAD RG 85 gyrocompass

SIMRAD AP-50 autopilot

Rudder angle indicator system

2 x FURUNO FE 700 echo-sounders

FURUNO speed log

DGPS

FURUNO GPS Sensor Mod. GD 150

FURUNO AIS FA 150

FURUNO NX-700 Navtex

FURUNO Wind Sonic wind instruments

Horn

Search lights 220W - 230V

Bridge navigation watch alarm

Ship’s onboard computer

COMMUNICATION EQUIPMENT

SATCOM

2 x FURUNO FELCOM 15 Inmarsat C

TRANSAS ECDIS

FURUNO & SIMRAD VHF radiotelephones

FURUNO portable VHF

2 x SAILOR handheld portable GMDSS VHFs

IRIDIUM satellite phone

Intercom - Talk back

PANASONIC telephone system

ZENITEL intercom system

VHF digital radios

FURUNO SSB MF/HF

EPRIB

FURUNO radar transponders

FURUNO NX-700 Navtex receiver

GMDSS battery plant 260 VA 24V CC GMDSS battery set

Guest phones in all areas and cabins

Internal ship’s communication system

ENTERTAINMENT, AUDIO/VISUAL AND IT SYSTEMS

Video Equipment

TVRO

VSAT TV system SEATEL 4006

Audio Equipment: Each stateroom is equipped with TV and AV rack with amplifier, DVD player and TV decoder, 2 x speakers and sub-woofer

Owner’s stateroom, main saloon and sky lounge have 5 x speakers and a sub-woofer

Remote controls

Main Salon: TV, AV rack with amplifier, DVD player, TV decoder, Play Station and Bluetooth connections

Master Stateroom: SAMSUNG LED LCD TV, ONKIO TX SR 608, YAMAHA YST SW 310, B&W SPK, ONKIO BD SP 308 DVD BLURAY, TOPFIELT HSCI 7700, PHILIPS Pronto

Remote control

VIP Stateroom: SAMSUNG LED TV, ONKIO LSV 501 amplifier, B&W SPK, TOPFIELT HSCI 7700, PHILIPS Pronto remote control

Guest Staterooms: SAMSUNG LED TV, ONKIO LSV 501 amplifier, B&W SPK, TOPFIELT HSCI 7700, PHILIPS Pronto remote control

Sky Lounge: TV, AV rack with amplifier, DVD player, TV decoder, Play Station and Bluetooth connections

Exterior, Aft Deck, Bar, Bridge Deck: 2 x Speakers on main deck aft, 2 x speakers on bridge aft deck, 6 x speakers on sun deck with additional amplifier

Captain’s Cabin: TV, decoder and car stereo

Crew Mess: TV, DVD player, decoder and car stereo

Hybrid Digital PABX / VOIP

GALLEY & LAUNDRY EQUIPMENT

Main Galley:

• 2 x AMBACH electric induction hob
• Extractor hood
• AMBACH multifunctional electric Braseria
• RATIONAL oven
• INKSINK Evolution 10 waste disposal
• PANASONIC microwave
• CUPPONE food mixer
• FRIGIT Blast chiller (Coldline) refrigerator / freezer
• MEIKO dishwasher
• Glass washer
• CASTEL MAC ice maker
• ROLLA dumb waiter

Pantries & Others:

• Refrigerators / Freezers in each pantry
• RATIONAL SCC61E oven

Crew Galley, Crew Mess, Laundry:

• LIEBHERR wine cellar
• 2 x MIELE washing machines Professional PW 6065 Vario
• 2 x MIELE dryers Professional PT7136 Vario

Sundeck:

• Refrigerator
• Grill

DECK EQUIPMENT

2 x 240 kg HV Type + 1 x emergency anchors

Anchor chains 350 m

Anchor Windlass System: 2 x Electric Vertical, DATA / HYDRO Systems DZC 3300 11 kW

Cranes: 1 x MOR SAVERIO C-079 Tel, capacity 1,200 kg, 1 x MOR SAVERIO C-0778 Tel Rb, capacity 600 kg

Warping Capstans: 2 x DATA / HYDRO Systems 7.5 kW

Bow crane

Passerelle: MOR SAVERIO hydraulic telescopic gangway

Side boarding ladder

Sea-stair

Swimming ladder

Jacuzzi for 6 x people on the sun deck

SPA / Sauna

Spotlights

Exterior paint in AWLGRIP

Interior paint

Underwater paint BOERO

SAFETY, SECURITY, & FIRE FIGHTING EQUIPMENT

PANASONIC CCTV

PANASONIC cameras

PANASONIC monitors

Ship’s safe

Doorbell

Fixed firefighting system

Firefighting equipment

Gas detection

Fire alarm

Systems alarms

MOB rescue boat

4 x 12 people life rafts

2 x Breathing apparatus

Lifejackets

Immersion suits

Life rings

EPIRBs

Flares

Medical Equipment

TENDERS & WATERSPORTS

Tenders:

• 1 x NAUMATEC Mod. TL 650 – with 220 Hp VOLVO Aquamatic D3-220 DPS engine, 44 Knots
• 1 x ZODIAC Yachtline de Luxe 380 – with 40 Hp YAMAHA outboard engine

Toys:

• AQUAGLIDE Park with Trampoline, floating Soaker / Lounge, Runway, Slide and Blast
• Water skis
• Wakeboard
• 2 x 2-Person inflatable kayaks
• 2 x Inflatable Paddleboards
• Towable toys
• 1 x SEA BOB F7
• Snorkelling sets

MAIN REFITS 2021 / 2022 / 2023

W6 Main engine service (2021/2022)

Revision generators (2021/2022)

Revision bow thruster (2021/2022)

Service of watermakers (2021/2022)

Service of refrigeration compressor (2021/2022)

Revision of fresh water pressure system (2021/2022)

New Evac pump (2021/2022)

Revision water softener (2021/2022)

Revision, cleaning, and disinfection of air conditioning system (2021/2022)

Revision black water pump (2021/2022)

Revision, wash, and flushing sprinkler (2021/2022)

Revision of frequency converter (2021/2022)

Hull painting (Winter 2022/2023)

Teak decks refurbishment (Winter 2022/2023)

Available on request.

Prior appointment, please.

Berth place management possible on French or Italian Riviera as well as Spain (Mainland and Balearic Islands), Greece and Turkey.

These particulars are given in good faith as supplied to us but cannot be guaranteed and cannot be used for contracts
